Lusya 2pcs MX50 SE SANKEN Audio Power Amplifier 2.0 Channels 100W Amplificador Diy Kit Finished Module

Lusya 2pcs MX50 SE SANKEN Audio Power Amplifier 2.0 Channels 100W Amplificador Diy Kit Finished Module

Name: Lusya 2pcs MX50 SE SANKEN Audio Power Amplifier 2.0 Channels 100W Amplificador Diy Kit Finished Module
Brand: MMO Dropship
SKU: 2251832686313514
Price: 72.84 VND
Availability: InStock
Rating: 4.9 (75 reviews)

Code: TD-2251832686313514 61 orders

Free Shipping

$ 72.84 $ 88.3

Color:

Note

Quantity:

Other people want this. 12 people have this in their carts right now.

Description
Shipping & Returns

Brand Name:	LUSYA
Certification:	NONE
Origin:	CN(Origin)
Maximum Power Per Channel:	100W
Model Number:	MX50
Package:	No
Channels:	2 (2.0)
Model Number:	MX50
Type:	DIY Amplifier
Voltage Gain GAIN:	34times
Supply voltage:	15V-45V

DIY Kit , need you solder it by yourself.

Features:

•The lower distortion, better control and resolution

•Single differential input, single-ended voltage amplifier stage, three-stage inverted Darlington output.

•The output stage uses the original KTB817, KTD1047

•PH-ILIPS KEC transistor, ST, EVOX producing CBB capacitor.KEMET, TDK monolithic capacitors.

Specification:

-Supply Voltage : DC + -15V to + - 45V

dual

12V- dual 32V

-Output Power: 15-100W 8ohm (+ - 42V)

-Voltage Gain : 34times

-Input Sensitivity: 1.2V100W 8 ohm

-SNR: More than 98DB

-Distortion: <0.009 THD 1K HZ 10W

-Output Stage quiescent current per channel Approximately 30MA

-PCB Dimension: 77mm * 74mm

Installation: 649 669 must be installed on supporting the radiator.

After the installation does not require any adjustment, the quiescent current of each tube about 30MA. This version does not need to fly line. Just take two bassoon installed in the radiator can be.

Package :

1Pair MX50 SE 2 channels Power Amplifiers Audio Diy Kit or finished board
