hp latex printhead 5pcs Stepping Motor Driver TMC2209 v3.1 Stepsticks Mute Driver 256 Microsteps Current 2.8A Peak 3d Printer Parts VS TMC2208 barcode printer head 3D Printer Parts & Accessories

hp latex printhead 5pcs Stepping Motor Driver TMC2209 v3.1 Stepsticks Mute Driver 256 Microsteps Current 2.8A Peak 3d Printer Parts VS TMC2208 barcode printer head 3D Printer Parts & Accessories

Name: hp latex printhead 5pcs Stepping Motor Driver TMC2209 v3.1 Stepsticks Mute Driver 256 Microsteps Current 2.8A Peak 3d Printer Parts VS TMC2208 barcode printer head
Brand: MMO Dropship
SKU: 33025556705
Price: 46.84 VND
Availability: InStock
Rating: 4.9 (96 reviews)

Code: TD-33025556705 79 orders

Free Shipping

$ 46.84 $ 53.36

Quantity:

Other people want this. 26 people have this in their carts right now.

Description
Shipping & Returns

Brand Name:	FYSETC
Origin:	CN(Origin)
Item Type:	DRIVER
Model Number:	tmc2209 v3.0
Model Number:	TMC2209 V3.0
characteristitic:	stepsticks mute driver
application:	Stepper motor driver
microsteps:	256
voltage range:	3.3-5V
current:	1.7A
Peak Current:	2.4A
with heatsinks:	yes
advantage:	super silent
function:	vs tmc2208

5pcs Stepping Motor Driver TMC2209 v3.0 Stepsticks Mute Driver 256 Microsteps Current 2.8A Peak 3d Printer Parts VS TMC2208

Features

Hardware compatible with StepStick and Pololu A4988

Drive capability up to 1.7A (RMS) continuous coil current - 2.8A Peak

Step/Dir interface with microstep interpolation (up to 256 microsteps)

Configuration via CFG pins or UART interface

Motor voltage: 5.5...28V

Logic voltage: 3.3...5V

RSense: 0.11 Ohm

stealthChop2 - for quiet operation and smooth motion

spreadCycle - highly dynamic motor control chopper (enableable via UART, OTP, CFG Pin)

coolStep - current control for energy savings

stallGuard4 - sensorless motor load detection

Package listing:

5*tmc2209

5*heatsink

gift:1*screwdriver

note:

every body have the only screwdriver,if you order more and need more screwdriver,pls contact us.

if not,we will only send out one.

More information,pls refer our Facebook

https://www.facebook.com/groups/197476557529090/?ref=bookmarks
