fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas Communications Antennas

Code: TD-1005003152881005 3 orders
Free Shipping
$ 199.87 $ 206.18
Quantity:
Other people want this. 8 people have this in their carts right now.
Brand Name:  AISANRAY
Certification:  NONE
Origin:  CN(Origin)
Gain(dB):  10
Model Number:  DX-S

Anytone walkie talkie AT-778UV dual band VHF 136-174MHz UHF 400-490MHz 25Watt 200CH FM mobile radio

Features:

Adopt Superior quality material, better technology and high quality radiator to ensure stable and durable operation

180 degree rotatable TFT LCD display

Full alloy body for heat radiation

Amateur mode and professional mode for different operation requirement

Distribute buttons reasonably, convenient for operation

Separate band width setting for each single channel, Wide 25K, Middle band 20K, Narrow band 12.5K

200 programmable memory channels, identified by editing name

Separate CTCSS, DCS, DTMF, 5 Tone setting for each single channel, rejecting extra calling from other radios

Various scan functions including CTCSS/DCS scan function

Smart menu control and PC programming control

Voltage level control

LCD brightness control

Automatic power on function

Main unit and microphone key lock function

5 Tone signaling for data transfer, alarm, all call, ANI, remote kill, remote waken

DTMF-ANI or 5 Tone-ANI for automatical calling recognition

Specifications:

General

Frequency Range

Dual Band, VHF 136-174MHz & UHF:400-490MHz

Number of Channels

200

Channel Spacing

25K(Wide band),20K(Middle band),12.5K(Narrow band)

Phase-locked Step

5/6.25/6.25/10/12.5/20/25/30/50KHz

Operating Voltage

13.8V DC ±15%

Squelch

Carrier/CTCSS/DCS

Frequency Stability

±5ppm

Operating Temperature

-20°c~+60°c

Dimensions

124(W)*163(D)*39(H)mm

Weight

About 0.64kg

Receiver(ETSI EN 300 086 Standard testing)

Wide band

Narrow band

Sensitivity(12dB SINAD)

≤0.25uV

≤0.35uV

Adjacent Channel Selectivity

≥60dB

≥60dB

Audio Response

+1~-3dB(0.3~3KHz)

+1~-3dB(0.3~2.55KHz)

Hum & Noise

≥45dB

≥40dB

Audio distortion

≤5%

Audio Power output

>[email protected] OHM

Transmitter(ETSI EN 300 086 Standard Testing)

Wide Band

Narrow Band

Power Output

25W/15W/5W

Modulation

16KØ F3E

11KØ F3E

Adjacent Channel Power

≥70dB

≥60dB

Hum & Noise

≥40dB

≥36dB

Spurious Emission

≥60dB

≥60dB

Audio Response

+1~-3dB(0.3~3KHz)

+1~-3dB(0.3~2.55KHz)

Audio Distortion

≤5%

Package Contains:

1× AT-778UV Dual Band Mobile Radio

1× Microphone

1× Mobile Bracket

1× DC power cable with Fuse Holder

1× Screw sets

1× Spare Fuse

1× User Manual

Photos:

fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
fiberglass antenna kit for helium hotspot AnyTone AT-778UV Dual Band Transceiver Mini Mobile Radio Station VHF 136-174 UHF 400-480MHz Amateur Radio Walkie Talkie 25W communications antennas
