Comica BoomX-U QUA 4 Channels UHF Wireless Lavalier Microphone for Camera Phone Video Shooting Interview Live Streaming

Brand Name:	Comica
Transducer:	Condenser Microphone
Set Type:	Transmitter Sets
Style:	Lavalier Microphone
Use:	Pro Studio
Origin:	CN(Origin)
Package:	Yes
Model Number:	BoomX-U QUA
Polar Patterns:	Omnidirectional
Certification:	CE
Certification:	FCC
Certification:	RoHS
Communication:	wireless
Antenna:	PCB Antenna
Polar Pattern:	Omnidirectional
Sound Pressure Level:	100dB
Signal/Noise:	75dB
Equivalent Noise:	19dBA
External Mic Input Interface:	3.5mm TRS
Battery:	Li-ion Battery 700mAh 3.7V
Battery Life:	6.5 Hours
Monitor Interface:	3.5mm TRS/TRRS
Feature1:	Microphone for pc
Feature2:	Condenser microphone
Feature3:	Wireless microphone
Feature4:	Microphone lapel
Feature5:	wireless lapel
Feature6:	Microphone for mobile
Feature7:	Microphone for phone
Feature8:	microphone for computer
Feature9:	microphone for blogger
Feature10:	Microphone for cell phone
Feature11:	microphone for radio
Feature12:	Microphones
Feature13:	Professional microphone
Feature14:	Professional wireless microphone
Feature15:	microphone for youtube recording
Feature16:	Wireless lapel microphone
Feature17:	Wireless guitar transmitter
Feature18:	Portable Audio & Video

Evaluation video（Russian）

：https://www.youtube.com/watch?v=sF-9Xn0Ti1U

Evaluation video（Brazil）

：

https://www.youtube.com/watch?v=gOTl4gYytWw

Thanks for purchasing COMICA BoomX-UQUA Wireless Microphone

To ensure bring you a good using experience, please read this manual book carefully before using and correctly install and operate

Main Features

.4-group UHF Wireless Microphone, Broadcast Level

.24 Channels, Support Multi-receiver Monitoring & Shooting

.180°Foldable Antenna, 120m Super-long Transmission Distance

.Support 4 Audio Tracks Mixing and Individual Output

. Support Charging While in Use, Battery Life Up to 6.5 Hours

.Internal and External Two Input Modes

. Support Auto-scanning/Manual Channel-setting

. LCF, 16-level Adjusted Gain Control, Optional Language, Muting Functions

.LCD Screen for Intuitive Power and Audio Dynamic Monitor

.Special Anti-loose Design for External Lavalier Mic

.Designed with Multi-functional Belt Clip and Compact

Notice

.Please make sure the IR sensor are closely aligned when pairing

.Do not block the antenna position to avoid any poor signal generated

.It is recommended toopen and adjust the antenna of transmitter and receiver to appropriate angle for stable transmission and long working distance

.It is recommended to unfold the antenna of receiver when using auto scan function, or it will easily cause the scan to fail

.Please choose to close the group to savepower of the receiver when there is no need for multi-group use

.It is recommended to keep a distance more than one meter between each transmitterwhen using IR sync function, or it is easy to cause mismatching

.The product belongs to high-precision instruments, please avoid falling, collision or pounding

.Do not use the equipment in the vicinity of heat source or interference source, such as radiator, oven, WIFI AP, intercom or next to the other wireless devices

.When the pick-up distance is close orit is used outdoors, please put on the wind muff to prevent sound burst or reduce wind noise

.Do not use the equipment in rain or in a damp environment to avoid short-circuit danger

.Please keep the product in a dry environment

Packing List

Main Parts:

Transmitter(TX)

Receiver (RX)

Accessories:

①3.5mm Mic Audio Input Cable

②Wind Muff

③3.5mm TRS-XLR Audio Cable

④3.5mm TRS-TRS Audio Cable

⑤3 in 1 Charging Cable

⑥Cold-shoe Quick Release Plate

⑦Carry Case

⑧User Manual

⑨Warranty Card

Specifications

Transmitter (TX)

Antenna

PCB Antenna

Polar Pattern

Omnidirectional

Frequency Response

80Hz ~ 20kHz

Sound Pressure Level

100dB

Signal/Noise

75dB

Equivalent Noise

19dBA

Sound Delay

<20ms

External Mic Input Interface

3.5mm TRS

Battery

Li-ion Battery 700mAh 3.7V

Battery Life

6.5 Hours

Net Weight

45g

Dimension

49x 22x 66mm

Operating Temperature

0℃~ 50℃

Storage Temperature

-20℃~ 60℃

Receiver (RX)

Antenna

PCB Antenna

Receiving Sensitivity

-90dBm

Signal/Noise

75dB

Equivalent Noise

19dBA

Sound Delay

<20ms

External Mic Input Interface

3.5mm TRS× 2

Monitor Interface

3.5mm TRS/TRRS

Battery

Li-ion Battery 1400mAh 3.7V

Battery Life

6.5 Hours

Net Weight

90g

Dimension

65x 17x 82mm

Operating Temperature

0℃~ 50℃

Storage Temperature

-20℃~ 60℃

Parameters

Transmitter (TX)

Channel Number

24 x 4

Carrier Frequency of Group A

568.125MHz~573.875MHz

Carrier Frequency of Group B

580.125MHz~585.875MHz

Carrier Frequency of Group C

574.125MHz~579.875MHz

Carrier Frequency of Group D

586.125MHz~591.875MHz

Transmitting Power

15dBm

Receiver (RX)

Channel Number

24 x 4

Carrier Frequency of Group A

568.125MHz~573.875MHz

Carrier Frequency of Group B

580.125MHz~585.875MHz

Carrier Frequency of Group C

574.125MHz~579.875MHz

Carrier Frequency of Group D

586.125MHz~591.875MHz

The latest BoomX-U QUA set:
