CJM30-10A2-S Capacitive Proximity Switch Sensor AC Two Line Normally Closed 220V security panic button Alarms & Sensors

CJM30-10A2-S Capacitive Proximity Switch Sensor AC Two Line Normally Closed 220V security panic button Alarms & Sensors

Name: CJM30-10A2-S Capacitive Proximity Switch Sensor AC Two Line Normally Closed 220V security panic button
Brand: MMO Dropship
SKU: 4001286719787
Price: 34.48 VND
Availability: InStock
Rating: 4.9 (94 reviews)

Code: TD-4001286719787 32 orders

Free Shipping

$ 34.48 $ 35.4

Other people want this. 22 people have this in their carts right now.

Description
Shipping & Returns

Brand Name:	BADODOSECURITY
Certification:	CE
Origin:	CN(Origin)

Product Introduction:

1>.Name: Proximity switch

2>.Model: CJM30-10A2-S

3>.Product Type: Polarity Protection

4>.Wire length: 1.2m

5>.Induction method: capacitive

6>.Shell material: ABS plastic

7>.Detection of objects: metal and non-metal

8>.Detection distance: 10MM adjustable

9>.Output current: 300mA

10>.Output form: AC two line normally closed

11>.Working voltage: AC 220V

Product Features:

1>.Proximity switch has the characteristics of travel switch and micro switch, and has sensor performance and reliable operation, stable performance, fast frequency response, strong anti-interference ability, waterproof, shockproof and corrosion resistant.

2>.Head detection surface + heat-resistant ABS, mixed plating material, the appearance is round without burrs, does not hurt the hand, heat resistance.

3>.High quality wire + good electrical conductivity, standard wire is thick, waterproof, oil proof, anti-aging, good electrical conductivity

4>.LED lamp bead + smart chip, when the signal is output, the bead is bright, and the smart chip detects the object sensitively.

5>.Adjustable distance, easy to operate, counterclockwise rotation, distance adjustment, clockwise rotation, distance adjustment

Note:

1>.Detecting objects of different materials, the detection distance is different, and attention should be paid during installation;

2>.Installation: Threaded installation, generally affected by temperature, voltage, etc.,is generally installed at 85% of the rated detection distance.

3>.The test surface should be regularly cleaned of metal dust and other deposits to avoid affecting performance;

4>.Ambient temperature: -25°C~+65°C; relative humidity: 35~95%HR;

5>.Vibration: Durability: 10~55Hz complex amplitude 1.5mm, X, Y, Z for 2 hours each;

6>.Impact: Durability: 500m / s (about 50g), X, Y, Z direction 10 times;

7>.For use in strong magnetic fields, shielded wires are recommended.
