tracking device 4G LTE GPS Tracker Car TKSTAR TK905 5000mAh 90 Days Standby Vehicle Tracker Locator Waterproof Magnet Voice Monitor track a cell phone location for free GPS Trackers

Brand Name:	Soufyane
Origin:	CN(Origin)
Certification:	CE
Certification:	FCC
Special Feature:	waterproof
GPS type:	GPS Tracker
Model Name:	TK905
Out Power:	W
GPS Geographic Location:	South America
Gps Module:	Yes
Screen Size:	No Screen
Voltage:	12V
Battery Life:	30 Hours & Up
Standby Time:	Around 90 Days
working time :	Around 7-10 days
Battery:	Chargeable 3.7V 5000mAh Li-ion B
Weight:	168g
network:	2G GSM 3G WCDMA and 4G LTE
Frequency1:	2G GSM 850/900/1800/1900MHz
Frequency2:	4G LTE 3G WCDMA: 850/900/1900/2100Mhz; 2G GSM:850/900/1800/1900Mhz
Magnetic:	Built-in 5pcs powerful magnets,Easy to be installed
Waterproof:	IP65
Web&APP Tracking Software:	iOS and Android available; Life Time Free!
Built-in Mic:	Support Voice monitor (only for 2G model)
Lifetime Free Tracking Platform:	Yes
Positioning Ways:	LBS+GPS

3.TURN ON THE DEVICE

Open the rubber cover, insert the SIM card(chip up) to the slot, the device auto starts.

The indicator light is on when SIM card is inserted.

The device gets GPS location when there is GPS signal and gets LBS location when there is no GPS signal.

The device automatically turns off when the SIM card removed.

4.SMS TRACKING

4.1. Call the SIM card phone number in tracker,you will receive a Google Maps link of position,

or sending message “G123456#” to SIM card phone number in tracker .

E.g:

4.2. Admin number setting (After admin number setting, all SMS operations to the device are under this number only.)

Command: admin123456 phone number(This phone number is your own mobile phone number , not the SIM card number in tracker .)

Reply admin ok

E.g admin123456 13265790180

When the unit is in over-speed alarm, shake sensor alarm, or low battery alarm, it will send alert to the admin number.( 13265790180 )

Admin number Canceling:

Command  noadmin123456

Reply noadmin ok

4.3. Over-speed Alarm setting( It works only in continuous positioning mode.)

Over-speed Alarm setting:

Command   speed123456 070 (Suppose speed is 70km/h)

Reply speed ok

E.g

When the unit speed is over 70km/h, it will send message “speed alarm!” to the admin number every 5 minutes.

Over-speed Alarm canceling

Command  nospeed123456

Reply nospeed ok

4.4. Shake Alarm setting

Command shock123456

Message Reply shock ok

E.g

Note:Pls keep the tracker being stationary for 5 minutes, this function will work.

The tracker will send SMS “sensor alarm!” to the admin number when the unit get shocked.

Shake alarm Canceling:

Command noshock123456

Reply noshock ok

4.5. Device working mode setting

Sleep by time mode setting

Command  sleep123456 time

Reply sleep time ok

E.g

(Tracker only works for 5 minutes after being waked up, and back to sleep mode, GPS shut off, GSM works in low consumption mode. SMS command, calling tracker can wake up the tracker.)

Sleep by shock sensor mode setting: (Factory setting is “Sleep by shock mode“)

Command sleep123456 shock

Reply sleep shock ok

E.g

(No shock for 5 minutes, the tracker will work in “sleep by shock” mode, GPS shut off, GSM works in low consumption. Vibration, SMS, calling can wake up the tracker.)

4.6 Terminal (

local) Time Setting(factory setting  GMT 0)

Command  :timezone123456 local time zone   Rep:time ok!

E.g: timezone123456 +1     timezone123456 -1    Timezone123456 0

4.7Reset Hardware

Command:begin123456

Reply:begin ok

E.g:

Pic 1:Replied real-time tracking information under GPS satellites signal.

Lat:22.63952 lon:114.17122  Positioning of the latitude and longitude values.

Spd:000  This refers to the device moving speed. The unit is km/h.

T:24/09/15  16:00  real-tracking time, the Default is London time. You can set language and time zone in APP.

Bat:100%  The battery value is between 10% and 100%. Once it is less than 30%, it alarms.

2015070203: Device IMEI No. to log in APP and platform.

Google Link: This is the link to the Google map showing the position of the device.

Pic 2:Replied LBS tracking information without GPS satellites signal.

Lac:27a4 1223:   Real-time LBS positioning data.

T:24/09/15 15:17 LBS positioning time.

Bat:100%  The battery value is between 10% and 100%. Once it is less than 30%, it alarms.

Last:T:25/09/15 03:04  This is the time when tracker got last GPS signal

Google Link: This is the position of last gps signal appeared

6. 0 START ONLINE TRACKING

Pls activate GPRS by sending command “gprs123456” when the tracker is on, and set APN by following steps.

Every sim card carrier has own APN content, we have two methods to find out apn content : check sim card carrier on internet or put sim card into cell phone to find out APN

Two steps to set apn:

1), Turn on gprs function by sending command “gprs123456”

2),Set apn by sending command “apn123456 content” , “apnuser123456 content” ,“apnpasswd123456 content” pls note the content is from SIM card carrier , there is small blank after 123456 in every command.

6.1 WEB ONLINE TRACKING

Platform : www.mytkstar.net

Select “Log in by IMEI” on the bottom of screen

IMEI No. : on the back side of cover

Password: 123456

Select “Log in by IMEI” on the bottom of screen

Server:  www.mytkstar.net

IMEI : on the back side of cover

Password: 123456

FOR  PC

6.3 Turn on GPRS function by sending command “GPRS123456” to the tracker, and set the APN for the tracker, then its online tracking by APP and platform works.   (if you did it already in 6.0, no need to it one more time )
