SMTAV Free Shipping SDI PTZ Camera 10X Zoom Live Streaming Camera For Church Business Metting Conference Camera mini dv camcorder for sale Camcorders
Code: TD-1005004160541740
Free Shipping
$ 499.5
$ 510
Other people want this. 13 people have this in their carts right now.
| Brand Name: | SMTAV |
|---|---|
| Origin: | CN(Origin) |
| Usage: | Professional |
| High Definition Support: | 1080P (Full-HD) |
| Model Number: | PV 10X-SDI |
| Certification: | CE |
| Certification: | FCC |
| Feature 1: | video conference camera |
| Feature 2: | camera with zoom |
| Feature 3: | IP CAMERA |
| Feature 4: | camera ips |
Product overview
An webconferencing camera for corporate, education and telemedicine applications with 10 x optical zoom and 60FPS high frame rates, combined with premium color restoration, captures stunning live images to capture quality color video images in corporate conference rooms, classrooms, training centers and medical rooms.With advanced control algorithm can achieve accurate, smooth and quiet PTZ control, the camera can easily cover all indoor people during video conferencing, equipped with 255 preset positions, allowing it to easily and quickly reproduce clear pictures, and without any interference to the speaker or audience.To facilitate control and viewing, it can output DVI and HDMI interfaces, while automatically receiving VISCA command and PELCO-P / D protocol commands, with the option to use RS232 or RS485 interface.
Product characteristics
l
Leading automatic focus technology
Advanced autofocus algorithms enable the lens to complete autofocus, quickly, accurately and stably
l
Positioning is precise, smooth, and quiet control algorithm PTZ control
Precision motor drive with advanced control algorithms, the operation is very quiet, smooth, smooth, can accurately and quickly move to the designated location, and conduct a large range of shooting.
l
Real FULL HD HD images
High-quality 1 / 2.8-inch, 2.1-megapixel effective HDCMOS sensor for 1920x1080 ultra-high-resolution premium images.The output frame frequency is up to 60 / 50 frames / second.While ensuring high definition, the focus is on meeting the demand for picture fluency。
l
Low noise and high signal-to-noise ratio
The 2D and 3D noise reduction algorithm based on motion estimation are applied to adopt a new generation of low-noise sensors to effectively reduce the noise.
l
Multiformat video output in full HD
Rich and perfect interface.Both HDMI signals, SDI interfaces are provided.
Supportfor 1080P60/50/30/25/59.94/29.97,720P60/50/30/25/59.94/29.97 and many other high-definition video standards.
l
255 Position preset positions
The 255 positions can be preset by the serial port, including horizontal, pitch, and doubling, and the preset data can be saved even when the camera is switched off.
l
Multi-function remote control
Equipped with a simple operation remote control, in addition to basic setting and control of level, pitch, doubling, etc., can set relevant parameters of the camera through the remote control menu (SDI and HDMI interfaces can display only).
l
Infrared remote control signal transmission function
In addition to receiving its own special remote control signal, the infrared remote control signal of the user video conferencing terminal can also be uploaded to the video conferencing terminal via a serial port, replacing the infrared receiving port of the user video conferencing terminal, so that the user terminal can be placed in the background.
l
Optional camera mirror image and flip function
The structure supports camera inversion and can be changed through the OSD menu or sending serial port commands.(SDI and HDMI interfaces can display only)
l
OSD Chinese and English menu function
Rich OSD menu, with remote control of Chinese and English OSD menu.(SDI and HDMI interfaces can display only)
Application
Conference system, telemedicine, distance teaching, etc
model
10X SDI HDMI IP
camera parameters
imaging sensor
A 1 / 2.8-inch high-quality HD CMOS sensor
Effective pixel
16:9 The 2.1 million effective pixels
Video format
USB3.0: 1080p60/50/30/25/10 720p60/50/30/25/20/10，
USB2.0: 1080p10，720p25/20/10，800X600P60/50/30/25,640X480P60/50/30/25
Lens zoom
10 x optical zoom, 12 x digital zoom f=4.7mm~47mm
angle of view
4.7 (narrow) - -62 (wide)
Minimalilluminationillumination
0.1Lux
white balance
Automatic / indoor / outdoor / manual
focus
Automatic / manual
iris diaphragm
automatic
shutter
automatic
noise-signal ratio
>50dB
I / O interface
HD video interface
HDMI、USB3.0 IP CVBS Audio
Control signal interface
8mini DIN
Control signal format
Baud rate：9600/4800/2400bps
Power interface
HEC3800 convenienve receptacle
The operating system is supported
Windows XP,Vista,7,8, Mac OS X, Linux
USB protocol
UVC1.1
The USB Interface PTZ Control
Support for PTZ control
General parameters
mechanical behavior
Horizontal rotation：±170；Turn pitch：-30～+210
Horizontal speed: 1-100 / s; pitch speed: 1-60 / s
Preset bit speed: level: 100 / s, pitch: 60 / s
Preset bit accuracy: 0.1 degrees
Number of preset bits: 255 users can set the preset bits
Color
black
Power adapter
AC110V-AC220VDC12V/2A
input voltage
DC12V(DC11.5-DC12.5V)
power dissipation
15W (max.)
Storage temperature
-10℃ to + 60℃
working temperature
0℃ to + 45℃
Dimensions (width X height X deep)
155mmX186mmX172mm
Weight (net weight)
2.5KG(1.3KG)
service environment
indoor
