Camera Mount Type: | Fixed Camera Mount |
---|---|
Material: | Carbon Fiber,Plastic,Metal |
Controller Battery: | No |
Origin: | CN(Origin) |
Indoor/Outdoor Use: | Indoor-Outdoor |
Video Capture Resolution: | 480P SD |
Remote Distance: | about 50M |
Aerial Photography: | Yes |
Controller Mode: | MODE2 |
Control Channels: | 4 Channels |
Package Includes: | Original Box,Camera,Batteries,Charger,Operating Instructions |
Recommend Age: | 12+y |
Remote Control: | No |
Model Number: | RTF Micro FPV RC Racing Quadcopter |
State of Assembly: | Ready-to-Go |
Certification: | CE |
Operator Skill Level: | Beginner,Intermediate |
Barcode: | Yes |
Flight Time: | about 15 min |
Type: | HELICOPTER |
Features: | App-Controlled |
Dimensions: | 11cm-30cm |
Warning: | NO |
Charging Voltage: | 110-240V |
Motor: | Brushless Motor |
Warranty: | == |
Charging Time: | about 2 hour |
Plugs Type: | USB |
Power Source: | Electric |
Double Antennas
Built-in 3.7V 1200mAh Battery
Support a key search frequency
RaceBand 40 channel Auto-Searching
Real-time video return 5.8G FPV Receiver
●
Small size and light weight;
●
Low power consumption, Working current 300~330mA;
●
Double antenna reception to make the signal more stable;
●
RaceBand 40 channel, Auto-Searching;
●
3.0 Inch 480*320 dot high brightness LCD screen;
●
Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
●
Built-in 3.7V/1200mAh high-capacity Li-ion polymer Battery;
●
Universal USB charging interface;
●
Real-time video return, Very low time-delay;
●
Bilingual menu in support of Chinese and English;
●
Support external video signal input;
●
Support AV signal output (Connect external DVR);
①
Key 1:
Short press for
MENU
mode; Long press (More than 3 sec) for
Power ON/OFF
.
②
Key 2:
Short press for
Auto-Searching
(Automatic selection of the strongest channel).
③
Key 3:
Short press for
Band+
(Change bands A-B-E-F-R circularly).
④
Key 4:
Short press for
Channel+
(Change channels 1-2-3-4-5-6-7-8 circularly).
⑤
Eye ring:
protect the surrounding parts of the eyes, so that the wear more comfortable.
⑥
Micro-USB Charging port:
Supports DC5V only.
⑦
Antenna port A:
RP-SMA male.
⑧
Charging indicator:
Red light when charging light; full power, the indicator goes off.
⑨
Antenna port B:
RP-SMA male.
⑩
AV Jack:
In RF receiving mode can output AV signal; In AV mode can enter the video signal.
⑪
Head band:
Adjustable headband.
Menu Operation Instructions:
In normal mode, press
Key 1
to enter the MENU mode.
In MENU mode:
①
Key 1:
Select the option bar.
②
Key 2:
Return to normal mode.
③
Key 3:
Value -.
④
Key 4:
Value +.
AV port Instructions:
Dimension Diagram:
Not included antennas and headband.
Safety instruction:
1.
Read the entire instruction manual to become familiar with the features of the product before operating.
2.
Age Recommendation: Over 14 years old. Using any near eye displays on children under 14 can cause eye development problems. This is not a toy.
3.
Please avoid wet or humid environments.
4.
Please use standard USB charger, charging voltage can only be 5V.
5.
AV output and Video input cannot work at the same time, It is forbidden to insert external video in RF receiving mode.
