Mini Wireless Pro Game Controller Turbo Gamepad Programming Kid Joystick for Ninteno Switch & NS Lite Console PC

Features:

1) This SWH handle is compatible with SWH host and also supports windows computers and other devices.

2) Without any driver, the handle can be used after connecting with SWH host.

3) The connection mode of single button connection is easy to operate.

4) This handle has built-in gyroscope to support action sensing function;

5) The built-in dual motor supports the double shock function, and also supports the continuous firing function.

6) Multiple wireless handles can be connected to the host at the same time.

7) In the case of charging the handle, you can also play the game normally.

8) This handle can be upgraded with updated software by connecting to the computer.

On line Guidance

1. Through wireless connection to SWH host:

A.Connect the handle to the host for the first time: turn on the SWH host, and in the main menu interface of the host, touch and click "handle" → "Change the grip" to enter the host pairing mode interface; on the handle, press and hold the "home" key for 4 seconds to turn on the handle, and the four LED lights will flash in a slow cycle at first, and then it will flash in a fast cycle after 4 seconds to enter the search state. When one (or more) led is on for a long time, the handle and the host are paired successfully. Press the "B" key to return to the main menu interface.

B. Connect the handle to the host again: press the home key to open the handle, and the handle is automatically connected with the host.

C. Handle back to host:

1. In the sleep state of the handle, press the home key to wake up the handle, and the handle will automatically connect with the host.

2. In the sleep state of the host computer, first press the power button of the host to wake up the host, and then press the home key of the handle to connect to the host (in the sleep state of the host, pressing any key on the handle directly cannot wake up the host).

2.Connect SWH host via USB cable:

On the main menu page of SWH host, click settings → handle and sensor → Pro handle wired connection to open the wired communication function of Pro handle of SWH host; connect the handle to USB port of SWH host base with USB cable, and LED4 on the handle will flash slowly; LED1 on the handle will flash slowly after connecting the machine.

3. Connect Windows computer via USB cable:

First, you need to download and install the x-360 driver to the windows computer; then connect the handle to the computer with USB cable, and the four LEDs on the handle flash slowly; after the handle driver is automatically installed, the corresponding LED on the handle flashes slowly, and the handle can be used. Support x-360 mode game. Please find the download method of x-360 driver on the network.

Note: under the x-360 mode of wired connection computer, there is vibration function and no gyroscope axis function.

4. LED indication

1) Four LEDs flash fast and cycle: the handle is searching for wireless device pairing; the handle is connecting back to the host through wireless code matching.

2) Led fast flashing: the handle battery voltage is lower than 3.6V; when it is lower than 3.4V, the handle will automatically shut down and cannot be turned on.

3) LED is always on: the handle and the host are connected by wireless.

4) Led slow flash: the handle is connected to the host through USB cable; when the handle is connected to the charger for charging, four LEDs flash slowly at the same time, and when fully charged, the four LEDs will go out.

Package Included:

1 x Wireless Bluetooth-compatible Gamepad

1 x Cable

Note:

Please allow 1-3mm differs due to manual measurement.

Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding
