BRZHIFI Audio Classic Class AB Power Amplifier Refer to Berlin 933 Audiophile Stereo Amp For Speaker Home Theater Sound HiFi

BRZHIFI Audio Classic Class AB Power Amplifier Refer to Berlin 933 Audiophile Stereo Amp For Speaker Home Theater Sound HiFi

Name: BRZHIFI Audio Classic Class AB Power Amplifier Refer to Berlin 933 Audiophile Stereo Amp For Speaker Home Theater Sound HiFi
Brand: MMO Dropship
SKU: 3256803385836855
Price: 638.01 VND
Availability: InStock
Rating: 4.9 (95 reviews)

Code: TD-3256803385836855 6 orders

Free Shipping

$ 638.01 $ 649.61

Color:

Voltage (V):

110V

220V

Note

Quantity:

Other people want this. 22 people have this in their carts right now.

Description
Shipping & Returns

Brand Name:	BRZHIFI
Origin:	CN(Origin)
Maximum Power Per Channel:	100W
Package:	Yes
Certification:	NONE
Model Number:	PA-933
Channels:	2 (2.0)

Feature：

1. Very low output impedance and high damping factor, with perfect low frequency control even though the output power is only 120W.

2. The output transistor is the original SANKEN transistor 2SA1295 and 2SC3264, and the main filter capacitor is up to 80000UF, ensuring powerful dynamics and abundant energy.

3. Potentiometer is Japanese precision ALPS27, no breakpoint all-copper a-core transformer, omron relay protection.

4. The input end is CMC of the United States, and the output end is pure copper terminal.

Product parameter：

Circuit structure: Fully symmetric differential X-AMP circuit.

Coupling: DC coupling.

Rated continuous output power:

Original nominal 70W @ 8ohms, 120W @ 4ohms, 240W @ 4ohms bridge.

Measured more than 100W @ 8ohms, 130W @ 4ohms.

Rated continuous output current: 8A.

Instantaneous output current: 17A.

Input sensitivity: 700mV.

Input impedance: 1.88k balanced; single-ended 12k.

Damping factor: greater than 3000 @ 8 ohms.

Gain: 30.5dB.

Frequency corresponding: -3dB @ 220kHz / rated power output.

Total harmonic distortion + noise:

0.002% @ 8 ohms / 10W / 1kHz / 22kHz bandwidth RMS.

0.011% @ 8 ohms / 70W / 1kHz / 22kHz bandwidth RMS.

Background noise: 85uV @ No signal input RMS.

Signal to noise ratio: 107dB @ rated power output RMS.

Size: 360*268*80mm.

Net Weight: 8.3kg.

Weight after packing: 10kg.

PA-933：Standard Chassis （the radiator is processed by tooth-shaped aluminum profile）

PA-933-2: Upgraded Chassis （the radiator is made of a single piece of aluminum CNC machining）
