musical instrument amplifiers The Latest 3.5W*2 6AD10 Tube Amplifier APPJ PA1501A Class A Desktop Audio, Frequency Response: 30-40Khz,Input Sensitivity 500mV sub amp Audio Amplifier Boards

Code: TD-1005003491375210 2 orders
Free Shipping
$ 331.84 $ 347.44
Voltage (V):
230V
115V
Note

Quantity:
Other people want this. 25 people have this in their carts right now.
Brand Name:  GZLOZONE
Certification:  CE
Origin:  CN(Origin)
Maximum Power Per Channel:  4W
Model Number:  6AD10
Package:  Yes
Channels:  2 (2.0)

Product description

:

PA1501A tube amplifier is the first tube amplifier launched in the APPJ workshop in 2015. It is an upgraded product of PA0901A.

PA1501A uses imported 6AD10 brand new stock electronic tubes. There are many brands of 6AD10 on the market that can be directly replaced, such as Grants Bradford, Amperex, RCA, Sylvania, Westinghouse, GE, Philco, ITT, Chief, Tung-Sol, CBS, Admiral, Standard , Arcturus, Raytheon, Zalytron, Aladdin, Zenith, Motorola, IEC, Amperex, Mullard, etc.

6AD10 is a late-stage thing in the history of electronic tube development. It is an indirectly heated cathode double pentode-pentode composite tube with excellent performance. We use low-power pentodes for voltage amplification, high-power pentodes for power amplification, and transformer coupling to transmit power.

The performance of the amplifier composed of 6AD10 is much better than that of the amplifier composed of 6BM8, ECL805, ECL82, and 6F3. It is manifested in three aspects, noise, frequency response, and power, especially power. The 6AD10 amplifier can output 3.5W, which is 6BM8. ECL805, ECL82, and 6F3 are incomparable, and the sound is better than EL84 and 6V6.

Specifications:

Tube: 6AD10

Power Output: 3.5W+3.5W @ 8 ohms

Frequency Response: 30-40Khz (+-1db)

Input Sensitivity: 500mV

Signal-to-Noise Ratio: -80dB / 3.5W

Residual Noise <0.5mV AC

Input AC Voltage: 100-250V AC

Power Consumption: 38W

Input Impedance: 10K ohms

Output Impedance: 8 ohms (Japan Z11-EI48*24 Output Transformers)

Dimensions: 160mm (w) x 134mm (d) x 125mm (h)

Weight: 2.5kg

Input: RCA Jacks

Output: Banana Jacks

AC: Standard IEC Jack with Fuse protection (2A Fuse)
